Pumps for acrylates / monomers / polymers (e.g. MMA, butyl acrylate)

Safe handling of reactive materials in plastics production

Monomers are reactive chemical compounds that can be linked together to form polymers through polymerisation. The most important examples include acrylic acid (C3H4O2), methyl methacrylate (MMA, C5H8O2) and butyl acrylate (C7H12O2).

Acrylates and monomers are predominantly produced and processed in continuous production processes. Typical applications include paints and varnishes, adhesives, plastics (e.g. Plexiglas®) and coatings for metals and building materials. The handling of these media, some of which are reactive, places high demands on operational safety, availability and process stability.

Aerial view of a dual carriageway highway surrounded by lush green forests and rolling hills, with cars and trucks in traffic.

Interesting facts about acrylates, monomers and polymers

Typical temperature range

+20 °C to +350 °C

Our references

Production of acrylic acid and acrylates

Acrylic acid and acrylates are among the most important raw materials for paints, coatings, adhesives and plastics. In large-scale production plants, high delivery heads and reliable operation are crucial to ensuring a cost-effective process.

Production of acrylic acid and acrylates

Application: Acrylates / Monomers / Polymers

Technician in white protective suit using an orange HVLP spray gun to paint a car body panel.

Requirement

Medium:MMA (methyl methacrylate)
Delivery rate:18 m³/h
Pumping head:440 m
Operating temperature: 76 °C
Advantages: Low NPSH, high head required

Hermetic Solutions

Pump:CAMT 41/6+6
Motor:N80rm-2
Pump type:Multi-stage CAM: 6+6 stages
Ex protection: EX II2 G EX de IICT4
Speciality: Tandem configuration, centre-mounted engine

Manufacturer of styrene plastics for the automotive industry

Butyl acrylate is used, amongst other things, in the manufacture of plastics for the automotive industry. There is a need for compact and reliable pumping solutions that ensure safe operation even at low NPSH values.

Manufacturer of styrene plastics for the automotive industry

Application: Acrylates / Monomers / Polymers

Dark grey car dashboard interior showing air vents, MODE and A/C control buttons, and textured plastic surface.

Requirement

Medium:butyl acrylate
Delivery rate:4 m³/h
Pumping head:85 m
Operating temperature: 20 °C
Advantages: V-Line version, 10-week lead time

Hermetic Solutions

Pump:CAM 30/4
Motor:N24L-2
Pump type:V-Line with short lead times
Ex protection: II 2 EG EX de II CT5
Speciality: Low NPSH, with inducer

Customisations

Can’t find your application here?

We’ll work with you to develop a suitable pump solution for your specific process requirements. Thanks to our many years of experience in handling critical media, we can also produce bespoke designs and specialised solutions.

Make an enquiry now

Get in touch with our experts

Are you planning a monomer application, or do you have any questions about conveyor technology, design or possible applications? Please contact our team of experts. We’d be happy to advise you.
