Pumps for LNG and LPG

Hermetic pump solutions for cryogenic liquid gases

LNG (Liquefied Natural Gas) and LPG (Liquefied Petroleum Gas) are liquefied gases used in industrial, energy and transport applications. LNG consists predominantly of methane and is liquefied at extremely low temperatures of around −162 °C, which significantly reduces its volume for storage and transport. LPG consists mainly of propane and butane and is liquefied at comparatively low pressure.

Hermetically sealed and reliable pump solutions are crucial for handling these media. Low temperatures, high vapour pressure and varying operating conditions place particular demands on pumping technology and plant safety. HERMETIC canned motor pumps enable safe and leak-free operation even under demanding cryogenic process conditions.

LNG/LPG industrial processing plant at night with illuminated pipes, towers, and vessels under a deep blue sky.

Things to know about LNG and LPG

LNG (methane)

  • Boiling point: approx. −162 °C
  • Cryogenic, liquefied natural gas
  • Significantly reduced transport and storage volume
  • High demands on materials and leak-tightness

LPG (propane/butane)

  • Liquefaction occurs even at moderate pressures
  • Typical components: propane and butane
  • Used in industry, energy supply and transport
  • High vapour pressure and varying operating conditions

Our references

Manufacture of chemicals

Hermetic pumping of methane and hydrogen mixtures in petrochemical processes under cryogenic conditions. (e.g. ethylene, urea, HDPE, LLDPE, LDPE, butadiene or rubber)

Manufacture of chemicals

Application: LNG and LPG

Close-up of a new winter tire tread pattern showing deep grooves, sipes, and zigzag channels for enhanced grip.

Requirement

Medium:Methan und Wasserstoff
Delivery rate:10,6 m3/h
Pumping head:151 m
Operating temperature: –98,1 °C
Advantages: Sicherer Betrieb bei tiefen Temperaturen, hohem Dampfdruck

Hermetic Solutions

Pump:CAMTV 32/5+0
Motor:N54p-2
Pump type:Mehrstufige Spaltrohrmotorpumpe in Vertikalausführung
Speciality: Niedrige Viskosität (0.07 CP), hoher Dampfdruck von 32,2 bar und Tieftemperatur des Mediums

Manufacture of speciality chemicals and polymers

Production of high-quality speciality chemicals and polyolefins, including HDPE, mLLDPE, PE100+ polyethylene for gas pipelines, POE, alpha-olefins and UHMWPE. Production takes place under cryogenic conditions, with high standards of operational safety and process stability.

Manufacture of speciality chemicals and polymers

Application: LNG and LPG

Large stack of black HDPE pipes with blue stripes stored outdoors at an industrial facility for LNG/LPG applications.

Requirement

Medium:Methan, Wasserstoff und Ethylen
Delivery rate:153 m3/h
Pumping head:129 m
Operating temperature: –98,7 °C
Advantages: Sicherer Betrieb bei tiefen Temperaturen, hohem Dampfdruck

Hermetic Solutions

Pump:CAMFTVmu 60/2
Motor:N74rm-2
Pump type:Mehrstufige Spaltrohrmotorpumpe in Vertikalausführung
Speciality: Umführungsleitung für sicheren Betrieb und gegen VerdampfungMagnettraglager  Tieftemperatur des Mediums

Customisations

Can’t find your application here?
We’ll work with you to develop a suitable pump solution for your specific process requirements. Thanks to our many years of experience in handling critical media, we can also produce bespoke designs and specialised solutions.
